ENLITE INFINITY

Brand
0 out of 5

KEY FEATURES:-

  • WI-FI CONNECTION CAPABILITY
  • BLE FOR CONFIGURATION AND COMMUNICATION WITH MOBILE APP
  • 2 X 10/100 ETHERNET PORTS
  • 2 X RS-485 & 1 X RS-232
  • 1X USB PORTS (OPTIONAL)
  • OVER-THE-AIR UPDATES

Submit the inquiry to get direct support from our product team

Added to wishlistRemoved from wishlist 0
Add to compare
  Inquiry
FUNCTION SPECIFICATION
ELECTRICAL Input Voltage Range : 24VDC Power Consumption : 5W max.

Polarity Protection : Reverse input shall not damage the unit

Short Circuit Protection : Shorting Input power supply terminals shall not damage the device

OCP : 1.5A DC current shutdown

OVP : Withstands over voltage up to 33VDC UVP : Withstands under voltage up to 9VDC

ESD : 2 KV external Voltage Spike or Human Body Contact

COMMUNICATION Wi-Fi or Ethernet & BLE
NETWORK SPECIFICATIONS Supports BACnet TCP/IP

Supports Modbus RTU, Modbus TCP/IP Wi-Fi connectivity

MQTT

SSL/TLS security

Data Frequency 5 minutes*

CERTIFICATIONS CE



Mechanical and Environmental Specifications:-

FUNCTION                                    SPECIFICATION
ENCLOSURE ABS Plastic type Enclosure
INTERFACES Type of Interfaces               Number              Indication

WiFi Network                               1                     Bi-Colored LED

Network Ethernet RJ45             1                     RJ45 LED

Ethernet RJ45                              1                     RJ45 LED

USB-A                                           1                     NA

RS485                                          3                     NA

RS232                                              1                     NA

COMMUNICATION & POWER CONNECTORS 1x 24V DC inputs (2 Pins)

2x 3 Pins Connector for RS485 Communication to access data from external device 1x Ethernet-1 for Modbus, BACnet & SNMP (for communication purpose)

1x Ethernet-2 for Internet connectivity purpose

1x USB for transferring external device data to Enlite Infinity device. 1x RS232 Communication to access data from external device

SWITCHES & MODES 1x Reset / Enable Switch
MECHANICAL DIMENSIONS 166 x 140 x 50mm
WEIGHT 350g
MOUNTING TYPE Vertical Wall Mount
OPERATING TEMP RANGE 0°C to 65°C
STORAGE TEMP RANGE -20°C to 70°C
OPERATING HUMIDITY 10%-95% RH (non-condensing)
STORAGE HUMIDITY 5%-95% RH (non-condensing)



Device Mechanical Details:-

The device measurement is as follows:

  • Length – 166mm
  • Width – 140mm
  • Depth – 45mm without wall mount plate
  • Depth – 50mm with wall mount plate
