Briquetting Hydraulic Machine “B-Hack”

Products Specification-

The B-Hack works on the same principle as BLP & B-Jack but, making it far easier to operate comparatively. It is an economical product best suited to be used for making Briquettes, out of the waste materials like Agricultural Waste, etc., but is also used for making Eco-Bricks.

Our B-Hack is a foldable & Semi-Automatic device that is easy to operate with a Uniquely Designed Hydraulic Cylinder. It contains a lever and an oil release valve. Upon pumping the lever, the compression action is achieved. Once the entire machine is assembled correctly, a mixture of agricultural waste and water is prepared and poured into the porous cylindrical entity (Basket). The mixture is compressed until all the water content it is drained out of the basket.

The resulting product is in the shape of the basket, in this case in a cylindrical shape, and BRIQUETTE is made. Then, the OIL RELEASE VALVE is released for the automatic upward movement of the piston to be correctly positioned for the next compression.

Application-

Majorly used as a substitute for coal, kerosene, firewood for COOKING & BOILING WATER purposes.

Technical Specifications-

• No. of People required to Operate: 1
• Time to set up the Equipment: 5-8 mins
• Production Capacity: 32-36 briquettes/hr
• Weight: 25 kg
• No. of hrs to harden the Briquettes:
• 10-12 hrs in direct sunlight after compressing
• Burns: 15-20 mins/briquette
• Ideal Dimension of Briquette:
• Dia 4 “x Height 4”
• Ideal Weight: 200 gm/briquette
• BRIQUETTING HYDRAULIC
• Comes with a great deal of
• JACK “B-HACK”

Advantages-

The B-HACK offers benefits over its preceding two models; BLP & B-JACK including The B-Hack works on the same principle More Compressing Force enough to as BLP & B-Jack but, making it far make an ECO-BRICK easier to operate comparatively. Semi-Automation: The compressing It is an economical product best suited to be used for making Briquettes, out action is manual but the upward movement of the waste materials like Agricultural of the compressing Disk is made automatic. Waste, etc., but is also used for making Increased Production Capacity. Eco-Bricks. Increased Hardness of Briquettes Our B-Hack is foldable & Semi-Automatic Formed. A device that is easy to operate with – Lesser Time for Drying the Briquettes. A Uniquely Designed Hydraulic Cylinder.
