SN |
DESCRIPTION |
PROPERTIES WE MEET |
INHOUSE TESTING FACILITY | TEST DONE AS PER CODE | ||
| 1 | MATERIAL COMPOSITION | Rock / Mineral Fibres bonded with Thermoset Resin. |
IS 8183 / |
IS 3144 |
||
| 2 | DENSITY RANGE | (kg/m3) | 48 – 150 . Tolerance +/- 15% | YES | IS 8183 / | IS 3144 |
| 3 | THICKNESS RANGE ( mm) | 25 – 100 . Tolerance : ± 2 mm | YES | IS 8183 / | IS 3144 | |
| 4 | SLAB DIMENSION (mm) | 1000 x 500 / 1200 x 500
Tolerance ± ½ % |
YES | IS 8183 / | IS 3144 | |
| 5 | SERVICE TEMPERATURE | Max 750o C | YES | IS 8183 / | IS 3144 | |
|
6 |
THERMAL CONDUCTIVITY
(K value @ 25oC Mean Temp) unit : w/mok |
48 kg/m3 = <0.035
64 kg/m3 = 0.034 144 kg/m3 = 0.032 |
NO |
IS 8183 / |
IS 3346 |
|
| 7 | COMPRESSIVE STRENGTH | 2.0 to 44.0 kPA | NO | |||
|
8 |
NOICE REDUCTION COEFFICIENT (NRC) | 25 mm = 0.65
50 mm = 0.85 100 mm = 1.00 |
NO |
ASTM C 423 |
||
| 9 | LINEAR SHRINKAGE AT MAX USE OF TEMP. |
Less than 1.5 % |
IS 8183 / |
IS 3144 |
||
| 10 | NON-FIBROUS CONTENT | Less than 15.0% | YES | IS 8183 / | IS 3144 | |
| 11 | MOISTURE ABSORPTION | Less than 1.5% by volume | YES | IS 8183 / | IS 3144 | |
| 12 | MOISTURE CONTENT | Less than 1.0 % | YES | IS 8183 / | IS 3144 | |
| 13 | ALKALINITY (pH value) | 7 – 9 | YES | IS 8183 / | IS 3144 | |
| 14 | COMBUSTIBILITY | NON-Combustible (Loss <5.0%) | YES | IS 8183 / | IS 3144 | |
| 15 | CORROSIVENESS | NON-corrosive | YES | IS 8183 / | IS 3144 | |
| 16 | CHLORIDE CONTENT | Max 0.0012 % | YES | IS 8183 / | IS 3144 | |
| 17 | SULPHUR CONTENT | Max 0.2% | YES | IS 8183 / | IS 3144 | |
| 18 | ODOR EMISSION | Not detected | YES | IS 8183 / | IS 3144 | |
| 19 | FUNGI / MOLD /VERMINS | Do NOT encourage growth. | YES | IS 8183 / | IS 3144 | |
| 20 | ASBESTOS CONTENT | NIL | NO | NIL | ||
| 21 | FLAME SPREAD | Does not spread Flame | NO | |||
| 22 | REACTION TO FIRE | Fire Resistant | NO | |||
| 23 | SMOKE DEVELOPED | Do NOT generate smoke even during intensive fire | NO | |||
| 24 | PACKING | COMPRESSED PACKING IN HDPE BAGS | ||||
