Resin Bonded Rock / Mineral Wool Slab (RB Slab)

The DHANROCK® RB Slab is a high-performance insulation solution composed of mineral fibers bonded with thermoset resin. It features FSK (Aluminium Foil) facing on one or both sides. With a density range of 48–150 kg/m3 and thickness options of 4, 50, 75, and 100 mm, this slab meets stringent standards (IS 8183 / IS 3144). Its dimensions of 1000 x 500 / 1200 x 500 mm, along with a service temperature of up to 750°C, make it a versatile choice for various applications. The DHANROCK® RB Slab also demonstrates excellent properties such as low thermal conductivity, non-fibrous content, low moisture absorption, and resistance to corrosion and fungi. Compliant with industry standards, this slab is packed in a compressed HDPE bag for convenience.

Added to wishlistRemoved from wishlist 0
Add to compare
  Inquiry


SN



DESCRIPTION



PROPERTIES WE MEET

INHOUSE TESTING

FACILITY

TEST DONE AS PER CODE


1



MATERIAL COMPOSITION

Mineral Fibres bonded with Thermoset Resin. Facing : FSK ( Aluminium Foil) one or both sides

IS 8183 / IS 3144 ASTM C-612

2 DENSITY RANGE 48 – 150 kg /m3.

Tolerance ± 15%

YES IS 8183 / IS 3144
3 THICKNESS RANGE 4, 50, 75,100 mm

Tolerance : -2 mm + 5 mm

YES IS 8183 / IS 3144
4 SLAB DIMENSION ( mm) 1000 x 500 / 1200 x 500

Tolerance ± 1/2 %

YES IS 8183 / IS 3144
5 SERVICE TEMPERATURE Max 750o C YES IS 8183 / IS 3144


6

THERMAL CONDUCTIVITY

(K value @ 25oC Mean Temp)

unit : w/mok

48 kg/m3 = <0 .035

64 kg/m3 = < 0.034

144 kg/m3 = < 0.032



NO



IS 8183 / IS 3346

7 LINEAR SHRINKAGE AT MAX USE OF TEMP. Less than 1.5 % NO IS 8183 / IS 3144
8 NON-FIBROUS CONTENT Less than 15.0% YES IS 8183 / IS 3144
9 MOISTURE ABSORPTION Less than 1.5% by volume YES IS 8183 / IS 3144
10 MOISTURE CONTENT Less than 1.0 % YES IS 8183 / IS 3144
11 ALKALINITY (pH value) 7 – 9 YES IS 8183 / IS 3144
12 COMBUSTIBILITY NON-Combustible (Loss <5.0%) YES IS 8183 / IS 3144
13 CORROSIVENESS NON-corrosive YES IS 8183 / IS 3144
14 CHLORIDE CONTENT Max 0.0012 % YES IS 8183 / IS 3144
15 SULPHUR CONTENT Max 0.2% YES IS 8183 / IS 3144
16 ODOR EMISSION Not detected YES IS 8183 / IS 3144
17 FUNGI / MOLD / VERMINS Do NOT encourage growth. YES IS 8183 / IS 3144
18 PACKING Compressed -HDPE Bag
