CI092 Cast Iron Y Strainer PN-16 (Screwed)

Brand
5 out of 5
  • Item Code: CI0092
  • Pressure Rating: PN-16
  • Testing Standard: Mfg. Standard
  • Size Range: 15mm to 50mm
  • Product Standard: Mfg. Standard

Suitable For

ci092

Submit the inquiry to get direct support from our product team

Added to wishlistRemoved from wishlist 0
Add to compare
  Inquiry

Material Specification

CI092 Cast Iron Y Strainer PN-16

P. NO. NAME OF PART MATERIAL SPECIFICATION
1 BODY CAST IRON BSEN 1561 Gr. GJL200
2 GASKET STAINLESS STEEL TYPE 304 1MM DIA PERFORATION
3 PLUG C.N.A.F. ——-
4 COVER CAST IRON BSEN 1561 Gr. GJL 200

ci092ci092

Dimensional Data

ci092
SIZE (mm) 15 20 25 32 40 50 65
L 102±2 128±2 145±2 145±3 180±3 211±3 244±3
~H 85 108 128 145 170 205 255
“Rp” 1/2″ 3/4″ 1″ 1-1/4″ 1-1/2″ 2″ 2-1/2″



Principle Features

INTRODUCTION
Leader ’Y’ type Strainer offers best solution for separation and segregation for pump protection, flow meter protection, valves protection, regulator protection. In water handling equipment it works to save from damage through sand or any other solid particles.

  • Designed to manufacturer standard.
  • Y’ Type pattern, Bolted Cover.
  • SS (Type 304) Screen Having 1mm Dia Perforation snugly fitted on machined surface to ensure no particle larger than the screen opening can escape around the end of the screen.
  • Filtration area approximately 3 times more than flow bore area of the body.
  • Body cavity with largest possible filtration area to counter decrease in flow rate caused by clogging.
  • Fine finish and smooth contours of flow way reduce the pressure drop.
  • Screen is guided both in body and cover.
  • Strainers may be installed in vertical lines and horizontal lines with effectiveness.
  • Cover of the valve acts as drain plug to drain out the foreign particles accumulated in the strainer.
  • Screwed Female BSP Parallel Threads to BS:21.

END CONNECTION

  • Screwed Female BSP Parallel Threads to BS:21.

UTILISATION & SERVICE

  • “LEADER” Cast Iron ’Y’ Type Strainer are suitable for above-ground installations.
  • Best suited for potable water, treated fresh water, neutral liquids & some gases.

WORKING PRESSURE

  • Maximum Working Pressure: 16 Bar.
  • See Pressure / Temperature Diagram.

TEMPERATURE LIMITS

  • Maximum Working Temperature: 220°C.
  • See Pressure / Temperature Diagram.

TEST PRESSURE (Hydrostatic)

Rating PN-16
Body (Hyd.) 24 Bar
